ASTM B206 Cu-Ni C70600 Wire, Cu-Ni 90/10 MIG wire, Cu-Ni C70600 Wire Suppliers and Exporters.
Bhansali Exports is an acclaimed 90/10 cupro nickel wire manufacturer and cupro nickel 90/10 wire supplier in Mumbai. We have accumulated years of industry experience and are sure to offer quality metal products that can compete globally. Our cupro nickel 90/10 wires are made to a high standard and tested to meet the quality and performance needed. We have ensured that our products are top quality, and our dedication has been rewarded with certifications like ISO.
Cupro nickel 90/10 wires, our wires are highly resistant to corrosion, especially in marine applications that’s why they are widely used in shipbuilding industries, desalination plants and heat exchangers. These wires also provide good thermal and mechanical performance. Being a prominent 90/10 cupro nickel wires exporter, we make sure that our products are designed according to customers' needs worldwide. We provide affordable prices for our Cupro Nickel 90/10 wires while maintaining the highest quality and our wires are manufactured in different sizes and standards to fit your projects.
- Manufacturing Process Of Cupro Nickel 90/10 Wires
- Specification Of Copper Nickel 90-10 Wires
- Types Of Cupro Nickel 90-10 Wire
- Other Types Of Cupro Nickel 90/10 Wires
- Cupro Nickel 90/10 Wire Equivalent Grades
- Chemical Composition of Cu-Ni 90/10 Wires
- Mechanical Properties of Cu Ni 90-10 Wire
- Cupro Nickel 90-10 Wires Industrial Application
Cupro Nickel 90/10 Welding wire, 90/10 Cu-Ni Electrode Wire, Cupro Nickel UNS C70600 Tig Wire Manufacturer in India.
Some industries we supply our products to include marine, power generation, oil & gas, and automotive industries where the properties of cupro nickel 90/10 wires are most desirable. There is a reason why our wires are chosen – it is because they perform well and do not require much attention for a long period. Timely delivery and quality service are top priorities for us. If you are searching for cupro nickel 90/10 wire suppliers from Mumbai or anywhere in the world, we are here to fulfil your demand with the best quality products.
Drawing and annealing
Extrusion
Rolling
Forming
| Standards | ASTM B206/ ASME SB206 |
| Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Wire Length | Cut Lengths: 0.125" to 72" No Limit on Spooled Lengths |
| Wires Diameter | 0.0004" to 0.040" 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
| Ultimate Strength (≥ MPa) | 580-750 |
| Wire Resistance (μΩ.m) | as standard |
| Wire Elongation (≥ %): | 28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Welded Wire Mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet |
| Wires Mesh Weaving Methods | Plain Weave, Twill Weave, Dutch Weave |
| Wire Technique | Cold Rolled, hot rolled |
| Wire Condition | M, Y, 1/2Hard |
| Offered in a wide range of packages including | Spool Reel Coil Bobbin Carrier Custom packaging provided from as low as 1lb to 200lb tapered plastics |
| Wire available in form of | Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire |
| Test Certificates | Wire Tensile Testing Wire Hardness Testing Metallographic Inspection / Investigation Corrosion Testing for Wire Chemical Analysis for Wire Alloy Verification Wire Wrap Testing Wire Elevated Temperature Testing Stress Rupture Testing (Creep) |
| Application & uses |
Hardware tools Metallurgy Machinery Construction Shipbuilding Petroleum Chemical plant Power sector Gas Industry |
-
90/10 Cupro Nickel Welding Wire
-
90/10 Cupro Nickel Wire Rope
-
90/10 Cupro Nickel Spring Wire
-
90/10 Cupro Nickel Wire Coil
-
90/10 Cupro Nickel Wire bobbin
-
90/10 Cupro Nickel Ribbon Wire
- Copper Nickel 90-10 Spring Wire
- Cupro Nickel 90/10 Wire
- CuNi 90-10 Wires
- 90/10 Copper Nickel Wire Spool
- UNS C70600 Wires
- Copper Nickel 90/10 Wire Rod
- ASTM B206 90/10 Cupro Nickel Wires
- Cupro Nickel 90/10 Industrial Wires
- 90/10 Cupro Nickel Core Wire
- Cu Ni 90/10 Cold Drawn Wire
- CuNi 2.0872 Wires
- Cu-Ni 90/10 Cold Heading Wires
- 90/10 Copper Nickel Wires
- Cupro Nickel 90/10 Wiremesh
- Copper Nickel 90/10 Ultra Fine Wire
- 90/10 Cupro Nickel Wire Price
- Copper Nickel C70600 Wire
- CuNi 90/10 Sub-ARC-Welding Wires
- Copper Nickel 2.0872 Wires
- Cupro Nickel 90-10 Free Cutting Wire
- 90/10 Cupro Nickel Wire Stock
- ASME SB206 Copper Nickel 90/10 Wire
- Cupro Nickel 90/10 Fine Wire
- Cu-Ni 90/10 Wires
- Cupro Nickel 90/10 Lashing Wire
- 90/10 Cupro Nickel Thick Wires
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel 90/10 | 2.0872 | C70600 |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 90-10 | 88.6 min | 1.0 max | .05 max | 9-11 max | 1.8 max | 1 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Copper Nickel 90-10 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
“ Check Bhansali Exports's offered Cupro Nickel 90/10 Wires Prices, Dimensions & Weight. Place an order or enquire about your requirements. We will glad to be service. ”
